Electrical Wiring Design Software

E3.cable supports block functionality for electrical wiring design: blocks can represent components, rack equipment, black boxes, PCBs, and whole systems and sub-systems. Connector pins are dynamically added to the blocks, and signal information is displayed alongside.

Views allow alternate representations such as single-line diagrams, wiring diagram and cable plans. Connectors can be represented as single pins in the schematic and then as the complete connector in the cable plan. Changes to any of the views, are immediately updated all related views.

Hierarchical systems and sub-systems can be represented as blocks. Signals and connections can pass between levels and sub-levels. Hierarchy enables top-down and bottom-up design, promotes design reuse and provides project leaders with a system level overview.

Blocks can be integrated with PCB design data. Interface connector and signal information from the PCB system is dynamically added to the blocks in E3.series. Changes to the PCB are re-imported and updated in the block. E3.cable supports most PCB formats and has bi-directional integrations with Zuken’s CR-8000.
