JTAG is a powerful tool for debugging boards, in-circuit programming of FLASH/FPGA devices and for boundary scan. JTAG can be used to debug your first piece of hardware straight through to the high-volume manufacturing process. But let’s talk about the boundary scan side of JTAG in this post. As products get smaller and printed circuit boards become more dense, the boundary scan function becomes more and more important. Why? Because the physical space requirements for test points, ideally 0.035″ to 0.045″(.89mm to 1.14mm), is simply not available. Another factor to consider is the high pin count BGA where soldering 100s or 1000s of pins can easily create shorts or opens. These faults can stop a board from ever getting to the functional test phase for debug. So, in a nutshell, boundary scan is a tool you should consider part of every design.

Simply put, a boundary scan test shifts in a series of 1s and 0s through a predefined path or chain that enters and exits the board at the JTAG connector. A large number of ICs support a boundary scan chain so those 1s and 0s shift from pin to pin on each JTAG supported device. And with some creative test coverage schemes, even devices that don’t support JTAG can benefit. The difference between the input pattern and output pattern at the JTAG connector can identify shorts or opens on the PCB.

On the manufacturing test floor, a good portion of a board needs to be operational to get to the functional test phase. And if you have a dead board (i.e., won’t boot) boundary scan can quickly and precisely identify the fault(s) preventing a boot. Dead boards are costly and boundary scan can make a dead board operational.

XJTAG has partnered with Zuken create a new plugin for Design Gateway and is offering it free of charge. The plugin, called XJTAG DFT Assistant, helps to validate correct JTAG chain connectivity, while displaying boundary scan access and coverage onto the schematic diagram through full integration with Design Gateway. So if you are using boundary scan today or want to incorporate it in your next design, the XJTAG DFT Assistant plugin is a tool you should be using. If you want to learn more or get the plugin, visit www.xjtag.com/zuken.
