DXF Data into CR-8000 Design Gateway Symbol Editor

Tech Tip: How to Import DXF Data into CR-8000 Design Gateway Symbol Editor

Menu

How to use the CR-8000 DXF Editor

Follow the steps below to learn how to import data into the DXF editor and into Design Gateway symbol:

  1. Create an empty symbol file in your library using the CR-8000 Engineering Desktop to import DXF data.
  2. Close the target symbol.
  3. Browse to the folder where the target symbol is stored.
  4. Select a symbol in the folder; any symbol can be selected at this point. Right-click and in the assist menu and select Tool > Data Import > DXF Import
  5. Browse to select the DXF file and then browse to select the target path and symbol.
  6. There are some options to set scale, and precision and so on.  Once you have made the appropriate settings, select Execute
  7. Open the symbol and review the results.
  8. Copy and paste this graphic into your drawing format.

Watch the video below for step by step instructions.
