DS-CR EDA Library Master

The DS-CR EDA Library Master (ELM), manages all symbols, footprints and specifications required for the PCB design process. EDA Library Master can be accessed from within the CR-8000 authoring environment. All library items managed in EDA Library Master are subject to DS-CR’s version management functionality. Geometry information and symbols can be supported for multiple sites and within specific library classes.

PCB Schematic Symbols

PCB Footprints

Pin Information

Related Documents

PCB Library Management Software

EDA Library Master can be accessed from within the CR-8000 authoring environment. Access to validated and approved libraries significantly increases engineering productivity by eliminating time-consuming and error-prone manual search practices.

All library items managed in our PCB library management software are subject to DS-CR’s version management functionality. Geometry information and symbols can be supported for multiple sites and within specific library classes.
