Tech Tip: Creating Cable Ducts and/or Wire Combs in the E3.series Database
Cable ducts are special devices used in E3.panel that can be created with or without a definition in an E3.series database. These cable ducts can be created and placed on panel sheets; they’re used to route wires from one location to another. They can also be used with automatic routing functionality so the wires are routed from start to finish using the shortest path, which would be defined by the cable duct.
E3.panel allows engineers to layout components inside panel enclosures in both 3D and 2D. Intelligent automatic snapping points allow parts to be easily placed in their correct location. Clashes can be prevented with keep-out and height restrictions.
E3.series is a true concurrent electrical engineering environment supporting advanced requirements for electrical documentation, cabinet and wire harness design and manufacturing outputs.
