E3.ConnectivityBrowser - Automatic visualization of a digital connectivity data model

E3.ConnectivityBrowser - Interactive Demonstration

Spend just 10 minutes and experience this innovative solution yourself in our interactive web environment.
Menu

E3.Connectivity-Browser is the only application able to read a pure digital connectivity data model and generate automatically high-quality schematic diagrams on the fly.

Register now to begin your guided and interactive software evaluation. After your registration we will send you a link by email which provides you the direct access to our web application.

In the web environment there will be a guided tutorial and in parallel you can directly try out all presented functions.

There are two version of the demo available, you can select which one you prefer at the start of the demo:

  • Vehicle Electrical Design (English)
  • Electrical Cabinet Design (German)

At the end of this 10 steps tutorial (each step takes max. 1 minute) you can continue to experience the innovative solution E3.Connectivity-Browser with our prepared sample design as you have the powerful functionality of the tool available.



What to expect

Below is a short recording to illustrate what you can expect.

  • Once you have selected your preferred demo, the interactive tutorial will start with an introduction movie outlining how software will work

  • The movie guide then shrinks to the corner of your browser and the main area becomes active, allowing you to interact with the software / components on screen, as shown below.

System Requirements

  • Screen Resolution: For best results, view at 1920 x 1080 pixels or greater

Register Today

Register to receive access details for the 10 minute interactive web-based evaluation.
