Zuken’s E3.series is used for documenting and detailing electrical and fluid design projects. Its flexibility supports the entire process from definition and design, through manufacturing and maintenance. Its unique object-oriented architecture ensures all stages of the design are fully synchronized.

E3.cable is an integrated design solution for interconnecting devices and designing cables and harnesses. Its intelligent block functionality enables engineers to quickly represent dynamic equipment such as line replacement units (LRUs) or electronic control units (ECUs), while the hierarchy functionality enables a top-down or bottom-up design approach. E3.cable also includes one of E3.series’ most powerful features; its ability to create multiple views of the same devices for design and documentation purposes.

Special functionality in E3.cable

  • Create block diagrams
  • Automatic mating connectors
  • Automatic connector pin terminals, cavity seals and crosssection checks
  • Inline connectors and splicing
  • Shielded, twisted pairs and cable bundles
  • Table-driven wire assignment
  • Multiple views of cables and connectors
  • Interface data from PCBs
  • Predefined functional assemblies
  • Display special connectors using MIL standard (optional)
  • Option and variant management
  • Hierarchical design
  • System rack design
