Hydraulic, Pneumatic, Cooling and Lubrication System Design

The need for integrated fluid and electrical design

Hydraulic, pneumatic, cooling and lubrication systems activated by electric motors or pumps require integrated handling of fluid and electrical designs. To ensure consistency, representations in both domains need to be interlinked.

We can help you with

Combined electrical and fluid design

With intelligent sheet formats offering easy navigation between electrical and fluid elements. BOMs show only a single instance of combined electrical and fluid elements (e.g. a valve).

Device ID assignment

Consistent, synchronized representations of electromechanical devices in pneumatic schematics, electrical schematics and installation diagrams through database controlled cross-references.

Design rule checking

Design rule checking with optimized functionality for the development of hydraulic, pneumatic, cooling and lubrication systems.
