Electrical Planning and Documentation

Develop your electrical projects in a seamless environment

The growing complexity of today’s control systems requires powerful tools for fast and error-free schematic designs and wiring diagrams, and support for design reuse.

fluid power design - Zuken

We can help you with

Database driven design

Continuous synchronization of all engineering stages are enabled by an object-oriented systems architecture built on a central database.

Online design rule checking

Built-in DRCs for part selection, duplicate device name prevention, short-circuit avoidance and incorrect wire gauge allocation.

Options and variants

Support of variants and options within a single design. All variantes can be managed as options with one single 150% schematic.
