Tech Tip: Introduction to the New Braiding Utility in Harness Builder for E3.series 25.01.00

Harness Builder for E3.series latest release (version 25.01.00), introduces a powerful new Braiding utility designed to give users more customization and control over harness design. This update makes it easier to define and apply braiding patterns to suit your specific project needs.

Where to Find the Braiding Function

The Braiding function is located within the Harness Builder for E3.series interface, making it easy to access during your design process. Users can quickly navigate to the tool and start creating custom braiding setups.

Customizing Your Braiding Settings

With this feature, you can:

• Define your own yarn and color combinations

• Adjust braiding angles

• Set percentage increases

• Customize various parameters to achieve the desired look and performance

Machine Compatibility

Currently, the braiding function is compatible with the OMA Braiding Machine. While it does not generate machine-specific files, the flexibility of the function allows it to be used with other machines as well. Additional machine compatibility will be added in future updates based on customer requests.

Recorded Using the Latest Versions

This demonstration was recorded using E3.series 2025 (V25.20) and Harness Builder 2025 (V25.01.00), ensuring you see the tool in action with the latest software capabilities.
